Product platform:U10/U10L
Product Model:BJ6103
Selling point:Euro II
Driver location:LHD
Fuel:Diesel
| 产品平台 Product platform | U10/U10L | |
| 产品型号 Product Model | BJ6103 | |
| 特征值 Selling point | 欧二 Euro II | |
| 基本参数 Basic specification | 驾驶位置 | 左舵 |
| Driver location | LHD | |
| 燃油 | 柴油 | |
| Fuel | Diesel | |
| 车身尺寸 | 10490×2500×3440（with A/C） | |
| Exterior dimensions（mm） | ||
| 结构 | 半承载 | |
| body structure | Chassis type | |
| 座位数（最大） | 55+1（3+2布置） | |
| Seat No.（max） | ||
| 整备质量（T） | 10.35 | |
| G.V.W(T) | ||
| 最大总质量（T） | 14.2 | |
| Max. gross weight(T) | ||
| 前悬/后悬（mm） | 2170/3150 | |
| Front/rearoverhang（mm） | ||
| 轴距（mm） | 5170 | |
| Wheelbase ( mm ) | ||
| 行李舱容积（m3） | 5.5 | |
| Luggage compartment（m³） | ||
| 最小离地间隙(mm) | 180 | |
| Min. ground clearance （mm） | ||
| 最高车速（km/h） | 110 | |
| Max. speed | ||
| 最大爬坡度（%） | ≥30 | |
| Max. gradeability(%） | ||
| 制动距离（V=30Km/h满载） | ≤10 | |
| Braking distance(V=30Km/h at full load)(m) | ||
| 车内噪声（V=50KM/h匀速） | ≤75 dB(A) | |
| Inner noise（50Km/H at constant speed） | ||
| 发动机 Engine | 品牌 | 玉柴 |
| Brand | Yuchai | |
| 型号 | YC6A260-20 | |
| Model | ||
| 额定功率 | 191 (260) / 2300 | |
| Rated power(kw(PS)/rpm) | ||
| 排量(升) | 7.255 | |
| Displacement（L） | ||
| 排放 | EURO Ⅱ | |
| Emission | ||
| 底盘 Chassis | 变速箱品牌 | 法士特 |
| Transmission Brand | FAST | |
| 变速箱型号 | S6-100 | |
| Transmission Model | ||
| 变速箱型式 | 手动 | |
| Transmission Type | Manual | |
| 离合器 | 进口萨克斯φ430离合器 | |
| Clutch | SCHASφ430 | |
| 缓速器 | 电涡流缓速器 | |
| Retarder | Electric retarder | |
| 车桥 | 前5T / 后10T | |
| Axle | Front 5T / rear 10T | |
| 悬架 | 板簧悬架 | |
| Suspension | Leaf spring Suspension | |
| 制动 | 前盘后鼓制动器 | |
| Braking | Front disk& rear drum brake | |
| 转向 | 整体式动力转向 | |
| Steering | Integral power steering | |
| 轮胎 | 11R22.5 | |
| Tyre | ||
| 油箱 | 310L | |
| Fuel tank capacity | ||
| 防抱死 | ● | |
| ABS | ||
| 冷却系统 | 机械风扇冷却 | |
| Cooling system | Mechanical fan | |
| 车身内外饰 Interior and Exterior | 行李架 | ● |
| Luggage rack | ||
| 地板 | 竹地板 | |
| Floor | Bamboo floor | |
| 地板革 | 耐磨防滑地板革 | |
| Floor leather | Anti-wear floor leather | |
| 冷风管道 | ● | |
| Cold wind pipeline | ||
| 乘客座椅型号 | J 型标准座椅 | |
| Passenger seat | Model J | |
| 乘客座椅数量 | 55（3+2） | |
| Passenger seat No. | ||
| 司机椅 | 机械减震司机椅 | |
| Driver seat | Mechanical damping driver seat | |
| 前乘客门 | ● | |
| Front passenger door | ||
| 中（后）乘客门 | ● | |
| Middle passenger door | ||
| 安全门 | 〇 | |
| Emergency door | ||
| 司机窗 | 内藏后推拉钢化玻璃窗 | |
| Driver window | Sliding windows | |
| 侧窗 | 单层封闭窗 | |
| Side-window | Single layer sealed window | |
| 前风挡玻璃 | 前夹胶玻璃 | |
| Front windshield | Laminating glass | |
| 后风挡玻璃 | 后钢化玻璃 | |
| Rear windshield | Tempered glass | |
| 行李舱门 | 手动上翻铝舱门 | |
| Luggage compartment door | Upturning aluminum door | |
| 外后视镜 | 双兔耳电动除霜 | |
| Exterior rear-view mirror | Double rabbit-ear type, electric with defroster | |
| 护栏 | ● | |
| Safety board | ||
| 窗帘 | ● | |
| Side curtain | ||
| 遮阳帘 | 双幅手动遮阳帘 | |
| Sun-visor | Double manual sun-visor | |
| 顶风窗 | 带换气扇 | |
| Top windshield | With ventilation | |
| 轮罩 | 半幅不锈钢轮罩 | |
| Wheel cover | Half stainless steel wheel cover | |
| 电器系统 Electric Appliance | 影音设备 | 硬盘播放器 |
| Visual and audio system | Hard disc player | |
| 倒车监控 | 〇 | |
| Back-up monitor system | ||
| 车内监控 | 〇 | |
| Inner monitor system | ||
| 照明系统 | LED顶灯 | |
| Light and signal system | LED roof lamps | |
| GPS行车记录仪 | 〇 | |
| GPS Recorder | ||
| 电子钟 | ● | |
| Electronic clock | ||
| 仪表 | CAN仪表 | |
| Dashboard | CAN dashboard | |
| 空调系统 A/C | 空调 | 松芝SZQ-IVF-D |
| Air-conditioner | Songz SZQ-IVF-D | |
| 制冷量 | 27500 kcal | |
| Refrigerating capacity | ||
| 压缩机 | ● | |
| Compressor | ||
| 暖风 | 〇 | |
| Heater | ||
| 除霜 | ● | |
| Defroster | ||
| 其它 Other | 灭火器 | ● |
| Fire extinguisher | ||
| 车载卫生间 | × | |
| Toilet | ||
| 安全锤 | 4个防盗报警安全锤 | |
| Safety hammers | Anti-theft alarm safety hammers | |
| 油漆 | 标准漆 | |
| Paint | Ordinary paint | |
| 发动机自动灭火装置 | ● | |
| Automatic fire extinguishing device in the engine compartment | ||
| 发动机舱高温报警装置 | ● | |
| Engine compartment temperature alarm device | ||
| 低温保护 | 〇 | |
| Cryogenic protection system | ||
| 配置说明 Specification | ● With 〇 Option × Without ●标配 〇 选配 × 无法匹配 | |
| Optional is not included in the quotation 选配不包含在价格中 | ||
