| Brand | VIEW C2 | |
| Type / Usage | Cargo | |
| Grade | S | |
| Body | Narrow body flat | |
| Back Door | Lifted back door | |
| Sliding Door | Single sliding door | |
| Engine Model | 4JB1T | |
| Engine Emission | Euro IV | |
| Engine Fuel type | Diesel | |
| Engine Power (Kw/rpm)_ | 70/3600 | |
| Engine Torque (N-m/rpm) | 225/1800-2300 | |
| Engine Displacement (ml) | 2771 | |
| Transmission | 5MT | |
| Main technical parameter | ||
| Dimension parameter | ||
| Design body external dimension (mm) | 4840x1695x1980 | |
| Wheel base (mm) | 2570 | |
| Mass parameter | ||
| Total mass (kg) | 3020 | |
| Kerb mass(kg) | 2005 | |
| Loading weight (kg) (including persons) | — | |
| Capacity (Person) | 3 | |
| Seating arrangement | 3 | |
| Type of the last seat | — | |
| Power performance | ||
| Max.speed (km/h) | >120 | |
| Fuel economy | ||
| Integrated operating condition of 100 km fuel consumption (full load)(L/100km) | >9.4 | |
| Function configuration | ||
| Chasis system | ||
| Wheel assy | Tyre | 195R15C |
| Steel rim+Cover | • | |
| Brake safety device | ABS+EBD • | |
| Interior trim | ||
| Type | Ordinary gray | • |
| Half a pack / all-inclusive | Half pack of interior | • |
| Ceiling | PVC+Non-woven | • |
| Steering wheel | Adjustable angle of the steering wheel | • |
| Ordinary PU | • | |
| Seat | Seat fabric | Knitting | • |
| The whole car seat belt | • | |
| Three-point seat belt of side seat | • | |
| The number of sun visors | 2 | |
| Body and accessories | ||
| Number of side sliding door | 1 | |
| Front and rear bumpers | Black bumper (With striae) | • |
| Blind window | Total blindness | • |
| Back door | Glass | |
| Door lock | Remote control central locking (Integrated key) | • |
| Front door | Electric window | • |
| Outside rear-view mirror | Manual | • |
| Outside rear-view mirror housing | Black housing | • |
| lamps and lanterns | high-mount brake lamp | • |
| Reversing radar(singing) | • | |
| Body sound and light alarms | • | |
| Comfort | ||
| Air-conditioner system | Air conditioner | Front | • |
| Warm braw | Front | • | |
| Audio device | Radio +AUX+USB | • |
| Number of speakers | 2 | • |
| Others | ||
| Others | Side outside antenna | • |
| Central storage box | • | |
| Number of cup stand | 2 | |
After 17 years of quality accumulation, with integration of global landscape design concept in classic vehicles, VIEW set comfort, safety, control and bearing, fashionable large space in one. Two series of wide-body CS2 and narrow-body C2, and 9-16 seats product can meet wider demands for enterprise reception, public transport, logistics and other different business.
The View CS2 Window Van is yet another masterpiece produced by Foton, with a length of up to 6 meters and 18 seats (17+1) coupled with latest Cummins 2,800cc Euro IV turbo-diesel engine that caters to transporting tourist with ample luggage space as well as being suitable for ferrying factory workers and students on a large scale.
Both View C2 and View CS2 vans are labelled as 3E products, namely Ease, Efficient and Excellent. ‘Ease’ is stipulated as impeccable product quality with minimum issues.
Featuring leading technologies such as the Cummins engine, the vehicle provides enterprises, public agencies and individual customers with great value, high efficiency and a fantastic driving experience.
–The View CS2 features upgraded brake lights, electric mirrors, an anti-glare rearview mirror as well as additional devices to ensure road safety.
–Equipped with a 3H high-strength body and strong anti-collision bars as well as reinforced front and rear bumpers, the View CS2 provides you with maximum protection during a collision.
–Dual airbags, a collapsible steering column and three-point seat belts are standard features that ensure the safety of the driver and passengers.
–The View CS2 features a roof emergency escape hatch and a safety hammer is in place with which the window can be broken in case of emergency.
