Foton Miler 4.5T Cargo Box

Highlights

Foton Miler 4.5T Cargo Box

Brand: Foton Miler
GVW: 4.5T
Loading weight:3T
Left/Right-hand drive: Left/Right-hand
Engine: 4F20, displacement: 1.968 L
Rated power/speed: 90 kW/3,200 r/min
Torque: 320 N.m/1,400 r/min–2,600 r/min

Product Content

Brand

Foton Miler

ModelBJ 1035 V5JV5-05
BodySingle CabinSingle Cabin
EngineModelDAN20LDAN20L
EmissionEur. IIEur. II
Fuel typeGasolineGasoline
Power ( KwZrpm )106 / 6000106 / 6000
TDrque ( N-mZrpm )195 / 4400195 / 4400
Displacement (ml)19981998
TransmissionDAT25R ( 5MT )DAT25R ( 5MT )
Size parameter
Design body external  dimension (mm)- Flat Box5165 x 1950 x 21355585 x 1950 x 2135
Cargo compartment  Dimension (mm)- Flat Box5165 x 1950 x 21353815 x 1850 x 400
Design body external  dimension (mm)- Closed cargo Box5200 x 1950 x 27255620 x 1950 x 2725
Cargo compartment  Dimension (mm)- Closed cargo Box3380 x 1850 x 18003815 x 1850 x 1800
Wheel base  (mm)27003000
Capacity parameter
GVW  (kg)34953495
Kerb weight (kg) – Chassis14551485
Kerb weight (kg) – Flat Box17651815
Loading weight  (kg)  ( including persons )20402010
Payload2T2T
Capacity  ( Person )22
Front axle1T1T
Rear axle2.5T2.5T
Rear axle ratio5.3755.375
Basic configuration
Interior trimHalf-inclusive••
Brake clearance self – adjusting arm.•
ABS••
Brake typeFrontDiskDisk
RearDrumDrum
Electronic  accelerator pedal••
Parking brake typeCentral drumCentral drum
Suspention SystemFrontLeaf spring, 3Leafspring,3
RearLeaf spring,  3+2Leaf spring, 3+2
EP polymorphic  switch••
Fuel tankPlastic ,60LPlastic ,60L
Tire Type185R15185R15
Central lock..
Electric window•.
Remote  control••
Automatic  headlights••
Electrically  adjustable headlights••
Halogen headlights••
Cigarette lighter.•
12V power socket••
One-key lock  car window lift ( no anti-pinch )•.
Door not  closed warning••
Forgotten key alarm••
Drivers seat  belt not fastened Alarm•.
Option configuration
ooo
9 inch MP5 +  reversing image  +  bluetoothoo
Mechanical shock – absorbing driver’s seatoo
Electric air conditioneroo
Flat Boxoo
Cargo Box ( Closed )oo
LCD Dashboardoo
Daylightoo
Electric  adjustable rearview mirroroo
Reversing radar  +  Craiseoo
PU seatoo

Foton is the world’s leading, China’s largest commercial vehicle enterprise.

To satisfy the demands of international consumers for urban logistics and transportation, Foton has set many years of truck building experience, absorbed cutting-edge technology from Europe and the US, and created Miler — a high-end light-duty truck brand, which boasts high quality, high performance, high flexibility, high economy and low emission.

Foton Miler’s story

1. Point to the air deflector — emphasizing that Miler is a new generation of products created by FOTON, the single-brand sales champion of Chinese light-duty trucks;

2.The high-end product was created by FOTON with an investment of 400 million yuan over 3 years;

3.Point to the front lamps — they are stylish, built according to modern art aesthetics, and meet the aesthetic standards of the new generation of users;

4.It will always make your eyes shine at first sight;

5.The vehicle has a tough and simple appearance, with more interior space compared to the competitors.

6.Front lamps and its coherent chrome-plated corner design make the front more avant-garde, and the full front design brings you a more powerful sense of visual impact;

7.Introduction to FOTON brand;

8.Diamond LOGO base and Reversing buzzer ensure no blind spots in the field of vision and enhance safety across the board;

9.The design of dual distant light and dual light sources, with high beam diameter of 70 mm and large projection area, makes night driving safer;

10.Introduction to vehicle styling;

11.Point to the front of the vehicle — it incorporates many fashion elements, which meet the aesthetic standards of the new generation of users;

12.Introduction to vehicle color — its fresh and soft bright colors convey a positive attitude towards life;

13.Tiffany blue, the romantic, warm, and fresh color, is the major color tone of the vehicle, which is a noble color between blue and green, known as the world’s most expensive blue, fully reflecting the product class.

Foton Miler Interior


Customized Foton Miler for you
1. Co-creation between factory and customer

20,000+ advice from light-duty truck users has been gathered;
Based on operation big data of Foton‘s millions of urban distribution users both in China and abroad;
“Customer-oriented” and 3 years of co-creation between factory and customer, to build a user-defined super truck.

2.Directional R&D

The R&D team of Foton Research Institute has spent three years building a new technology platform targeting low cost, high efficiency, high income, and high comfort, aiming at more than 20 subdivided urban distribution scenarios and 80+ working conditions for light-duty trucks.

3.Authority participation

CATARC — China’s automotive R&D authority, is fully involved in the research and development of Miler;
From the initial user investigation, to more than ten times product improvement, to the final vehicle performance verification, Miler, CATARC, and its users achieve comprehensive participation in production, research, and use to create a win-win situation.

4.Extreme road test

The team formed by Miler, Aucan, and CATARC carried out the vehicle performance verification under extreme environments, i.e., plateau (Tanggula Pass, 5,231 m above sea level), high temperature (Turpan, average temperature of 45°C), and cold (Hailar, –40°C) on Miler trucks, as well as 2 million km of comprehensive real-world road testing.

FOTON Miler — a lightweight truck brand for city logistics and distribution

There are more than 700 outlets of sales and service in overseas markets for Foton LDT brand(Aucan engine), covering more than 80 countries and regions.

Foton Miler – Talk to Foton Miler Styling Engineer
